Playback | Digital Multimedia |
---|---|
Screen Size | 7" |
Size | Double Din |
Peak Power | 240W (60W x 4) |
Phone Connectivity | Android Auto, Android Auto Wireless, Bluetooth, CarPlay, CarPlay Wireless |
Bluetooth Features | Audio Streaming, External Microphone, Hands-free Calling, Phonebook Support, Voice Activation Button |
Inputs | Front View Camera, Rear View Camera, USB x 2 (Rear) |
USB Charge | 2.1A |
File Playback | FLAC, MP3 |
RCA Outputs | 3 Pair (Front + Rear + Sub) |
Audio Processing | 10 Band EQ, 7 EQ Presets |
Chassis Depth | Slim Mount (3.5") |
Illumination | 6 Preset Colors |
Steering Wheel Control Compatible | Yes – Adapter Required |
Wallpapers | 3 Selectable |
AM/FM Receiver | 30 Station presets (18FM/12AM), RDS |
Documents
Firmware
Firmware Update Instructions
This update addresses the following:
- Improved touchscreen response time.
- Change the Safety Notice screen to disappear automatically after 2 seconds.
- Change Rear Camera View settings from on to off (default: OFF).
- Add Time Sync Settings – OFF/GPS/RDS/Phone (default: OFF).
Note: Software is not interchangeable between models. Please do not attempt this update on any model
other than the CAR723W.
How to Update:
- Download the firmware file from the link below.
- Unzip the downloaded file. Note: To unzip the file, the program WINRAR is required and can be
downloaded from this link:
WINRAR Download - Copy the
ISPBOOT.BIN
file to an empty USB Thumb Drive formatted to FAT32. - Insert the USB Thumb Drive with Update Firmware into the CAR723W USB/Charging Port.
- Navigate to Settings and scroll till you get to the About button on the left
side of the menu. - Press the About button and you will see on the right-hand side Software
Update. - Press Software Update and you will see the Update button. Press
Update to begin the firmware upgrade. - Once the update is complete, remove the USB thumb drive.
- The update is now complete.
Download Firmware Zipped File: CAR723W Firmware Download
