Playback | Digital Multimedia |
---|---|
Screen Size | 7" |
Size | Double Din |
Peak Power | 240W (60W x 4) |
Phone Connectivity | Android Auto, Android Auto Wireless, Bluetooth, CarPlay, CarPlay Wireless |
Bluetooth Features | Audio Streaming, External Microphone, Hands-free Calling, Phonebook Support, Voice Activation Button |
Inputs | Front View Camera, Rear View Camera, USB x 2 (Rear) |
USB Charge | 2.1A |
File Playback | FLAC, MP3 |
RCA Outputs | 3 Pair (Front + Rear + Sub) |
Audio Processing | 10 Band EQ, 7 EQ Presets |
Chassis Depth | Slim Mount (3.5") |
Illumination | 6 Preset Colors |
Steering Wheel Control Compatible | Yes – Adapter Required |
Wallpapers | 3 Selectable |
AM/FM Receiver | 30 Station presets (18FM/12AM), RDS |
Manuals (PDFs)
Firmware
This update addresses the following:
1. Improved touchscreen response time.
2. Change the Safety Notice screen to disappear automatically after 3 seconds
Note: Software is not interchangeable between models. Please do not attempt this update on any other model then the CAR723W
How to Update:
1. Download the firmware file from the link below.
2. Unzip the downloaded file. (NOTE: To unzip the file, the program WINRAR is required and can be downloaded from this link: https://www.rarlab.com/download.htm)
3. Copy the ISPBOOT.BIN file to an empty USB Thumb Drive formatted to FAT32.
4. Insert the USB Thumb Drive with Update Firmware into the CAR723W USB/Charging Port.
5. Navigate to Settings and scroll till you get to the About button on the left side of the menu
6. Press the About button and you will see on the right hand side Software Update
7. Press Software Update and you will see the Update button. Press Update to begin the firmware upgrade
8. Once the update is complete, remove the USB thumb drive
9. The update is now complete
Download Firmware Zipped File: CAR723W Firmware
